Ecodata is a professional Internet e-commerce-based engineering company, relying on the portal site, mainly for domestic and foreign customers in the bulk material handling industry to provide engineering, technology and product supply services, including design and consulting, general contracting, equipment integration and so on.
Our Technical Support
The company has a team of experienced engineering and technical experts, can provide customers with the overall design of bulk material transportation program, the design information provided are:
- Installation layout plan
- Equipment list
- Construction program
- PID schematic diagram
- Electrical schematic diagram
- Water, electricity and gas consumption table, etc.
We will be the design of many years commonly used conveying equipment models, performance, introduction, organized into a mall products, relying on the Yingke mall list sales, to bring customers the most intuitive selection experience.
Website year-round customer service online for global customers to provide selection, quotation and technical Q&A service.
Design Case of Equipment Drawings
Drag Chain Conveyor
Chain conveyor machine drawings, show drawings for stone conveying,
is a double-row chain conveyor with resistance to large particles.
Lime mud Conveyor
Chain conveyor machine drawings, show drawings for lime mud conveying,
is a double-row chain conveyor with resistance to large particles.
Bucket Elevator
TH type bucket elevator drawings, show drawings are used for hoisting and conveying in flour industry,
it is a kind of equipment with wire rope core belt as chain, which is characterized by large conveying capacity and high efficiency.
U type Screw Conveyor
The screw conveyor in this case is used for the transportation of wood.
100+ conveying products, 100,000+ variant configurations, customized conveying products for customers , start your inquiry now!
Join us and make your company a better place.
Design Case of P&ID
Customized and optimized processes for our customers.
Silo
The material warehouse is a place where fly ash is stored collectively. Depending on the characteristics of different materials,
dust collectors, fluidized air, activated hoppers, vibrating motors, level gauges and other devices with different specifications
can be selected and installed.
Customized and optimized processes for our customers.
Pumped ash conveying system
under the electrostatic precipitator
Under the electrostatic precipitator, the three ash hoppers EP1,EP2,EP3, through the air slide,
are conveyed to the tandem silo pump, and then through the pipeline to the ash silo 1km away.
Customized and optimized processes for our customers.
Material cooling and pneumatic conveying
Material cooling and pneumatic conveying. Water-cooled spiral is used for cooling, and the transfer hopper
is also equipped with a water-cooled jacket. A high level switch is installed in the transfer hopper. When the level switch
receives a signal, pneumatic conveying is started. In this system, Venturi is used as the transmitter for pneumatic conveying,
which is a negative pressure conveying scheme.
Customized and optimized processes for our customers.
Drag Chain conveyor
system under bag filter
Fly ash from the dust collector is transported through the chain conveyor,
via a three-way valve (for switching between one use and one standby), into the aggregate chain conveyor
Customized and optimized processes for our customers.
Weighing and mixing of material
In this system, there are two powder weighing hoppers and 1 liquid weighing hopper configured. When the weight of all three hoppers
reaches the specified value, the feeding process is stopped, the discharge valves of the hoppers are opened, and the materials are then fed into the mixer.
